Mazak CNC Dual-Spindle Lathe w/ Gantry Loader

Description

CNC Turning Center w/ Gantry Loader
Manufacturer: Yamazaki Mazak Corporation (Made in Japan)
Model: Super Quick Turn 18MS (SQT 18MS)
Serial No.: 105503
Date of Manufacture: 1993
Electrics: 460 Volt, 3 Phase, 60 Cycle

Features and Specifications:
...CNC Control: Mazatrol T32-3
...Swing: 20.9”
...Swing Over Carriage: 15.74”
...Max. Machining Length: 20.47”
...Max. Turning Diameter: 11.75”
...No. Axis: 2
...Chuck Size: 10”
...Bar Capacity: 2.5”
...Max. RPM (both spindles): 4,000 RPM
...Travels:
.....X-Axis: 7.125”
.....Z-Axis: 22.75”
...Live Tooling Capable
...Rapid Traverse: 1,181 IPM
...Turret Capacity: 12 Slots
...Tool Eye
...Mazak Flex-GL100N Robot Gantry Loader
...Tooling:
......10" Kitagawa B-210 3-Jaw Chuck
......(10) Mixture of Live, Standard Tool Holders
(shown wrapped in plastic, on skid)
...Chip Conveyor
...Full Set of Operation, Maintenance, Parts Manuals

Dimensions (approx.): 120” x 72” x 88” (main CNC unit only)
Gantry Dimensions (approx.): 62” x 108” x 88” (requires confirmation)
Weight (approx.): 12,500 lbs. (n/i chip conveyor)

Approximate specifications taken from 1st-hand inspection, owner interview, manuals, and OEM research. While specifications are assumed accurate, confirmation by purchasing entity is always recommended.

Functionality & History Notes:

The machine is a 2nd-owner machine, well-maintained over its life and in good running condition. Comes with a robotic gantry part loader, chip conveyor, hydraulic chuck, and various tooling.

This owner purchased from the original owner during October 2023; he has requested I resell it due to electrical restrictions. His shop does not have the amperage service required to run machine and loader. The new owner does not want to increase his amperage service to the building.

Both parties are customers of MD Equipment Services (MDES). I took a video of the equipment when it was installed at original owner’s shop in June of 2023.

CALL FOR DETAILS, SCHEDULE INSPECTION
WE ARE OPEN TO OFFERS

EQUIPMENT LOCATION: Eugene, OR Metro Area

Equipment is presently assembled but not under power.
Available for inspection in As-Is condition.
Buyer responsible for loading expenses onto their transportation.
Buyer responsible for freight logistics and expenses.
MD Equipment Services can quote rigging, loading quote by professional rigger.

Contact MD Equipment Services LLC to schedule an inspection or arrange purchase details.
