Akira Seiki RMV 500-APC Vertical Machining Center

Description

Dual-Pallet Vertical Machining Center
Manufacturer: Akira Seiki (Taiwan)
Model: RMV 500-APC
DOM: 12/2011 (New in 2012)
S/N: On Request
Electrics: 220 Volt, 3 Phase, 50-60 Hz, 26 FLA
Main Motor: 13 HP

Features and Specifications:
...CNC Control: Akira Mi645 (Fanuc Code Compatible)
...Table Size: 20” x 12”
...Table Load (approx.): 220 lbs.
...Travels:
......X-Axis: 19.69″
......Y-Axis: 11.81″
......Z-Axis: 11.02″
...Spindle Specifications:
......Speed (max.): 20,000 RPM
......Taper: HSK40A
......Air Cooled
...ATC: 24 Slots + 1
...Tooling Specifications:
......Max. Diameter: 1.97"
......Max. Tool Length: 6.89"
......Max. Tool Weight: 5.51 lbs.
...Feeds:
......Standard Cutting (X,Y,Z): 394 IPM
......Rapid Traverse (X,Y,): 2,362 IPM; (Z): 2,834 IPM
...Pendant Control
...Centralized Lubrication
...Coolant System
...Mist Collector
...2-Pallet Shuttle
...No Vises

Dimensions (approx.): 112” x 60” x 118” Tall (top of mist collector)
Weight (approx.): 9,300 lbs.

Advertised specifications and functionality history is taken from 1st-hand inspection, owner interview, manuals, and OEM research. While specifications are assumed accurate, confirmation by purchasing entity is always recommended.

Functionality Notes and History:

Current owner is trimming down the number of machines he is running in his shop for efficiency purposes. This machine has been a good runner but he has chosen to run production on another machine. Unit is under power; available for inspection and test.

CALL FOR DETAILS, SCHEDULE INSPECTION
WE ARE OPEN TO OFFERS

EQUIPMENT LOCATION: Albany, OR Metro Area

Equipment is available for inspection; under power.
Buyer responsible for equipment loading expenses.
Buyer responsible for freight logistics and expenses.
MDES can provide rigging, loading quotations.

Contact MD Equipment Services LLC to schedule inspection or arrange purchase details.
